Rated charge current:10A/20A/30A/40A/50A/60A
LVR : Maintenance-free lead-acid battery, GEL lead-acid Flooded battery:12.6V
LVD : Maintenance-free lead-acid battery, GEL lead-acid Flooded battery:10.8V
Static loss: ≤ 50mA
HVD: Lead acid battery: 16V
Light control voltage: 5V/10V
Temperature compensation coefficient: -4mV/°C/2V(25°C)
Discharge loop voltage drop: ≤0.2V
LCD temperature:-20°℃~+70℃
Operating temperature:-20℃~+55℃
Storage temperature:-30~+80℃
Working humidity:≤90%,No condensation
Protection class:IP30
Grounded type:Positive grounded
Apertureforinstallation:Ф5mm
Above the parameters are in 12V system at 25°C, twice in 24V system.
